Description:
Performance requirements:
1 opening and closing torque, under the nominal pressure, the valve
opening and closing the
required maximum torque should not exceed 6Nm
2 air tightness, under the nominal pressure of 1.1 times, the valve
is closed and any open state
should be no leakage.
3 vibration resistance, under the nominal pressure, the valve
should be able to withstand the
amplitude of 2mm, frequency of 33 Hz 1/3 vibration, the valve on
the threaded connection should
not loose, there is no leakage.
4 temperature resistance, under the nominal pressure, the use of
the area of the valve
temperature is divided into: general area of -20~60 degrees
Celsius. In the allowable
temperature range, should not leak.
| Model | Product name | Medium | Service Pressure(MPa) | Inside nominal diameter(mm) | Outlet thread mm | Temperature or pressure of safe apparatus(MPa) | Thread connected to cylinder (mm) |
| QF-2P | Flapper-type oxygen valve | oxygen, atmosphere nitrogen | 15 | 4 | W21.8×1/14 | 21±1.5 | GB8335 PZ27.8
|
QF-2P1
| Flapper-type oxygen valve |
oxygen, atmosphere nitrogen | 15 | 4 | W21.8×1/14 | 21±1.5 |
GB8335 PZ27.8 |
QF-2P2
| Flapper-type oxygen valve | oxygen, atmosphere nitrogen | 15 | 4 | G5/8 | 21±1.5 | GB8335 PZ27.8 |
QF-2P3
| Flapper-type oxygen valve | oxygen, atmosphere nitrogen | 15 | 4 | CGA320 | 21±1.5 | GB8335 PZ27.8 |
Competitive Advantage:
1.Low MOQ: It can meet your promotional business very well.
2.OEM Accepted: We can produce any your design.
3.Good Service: We treat clients as friend.
4.Good Quality: We have strict quality control system .Good
reputation in the market.
5.Fast & Cheap Delivery: We have big discount from forwarder
(Long-term Contract).
Our Innovation:
Quality & Service At Freedom, our #1 priority has always been
providing our clients with great
quality products and superior customer service.
Quick Lead Time We're dedicated to providing the quickest
turnaround times and work very
Hard to ensure that all of your deadlines are met.
Unbeatable Prices We continuously strive to find ways of reducing
our production costs.
