ISO98.9-3 Steel Gas Cylinder 1.8L-50L High Pressure Gas Cylinder
High Corrosion Resistance
Specifications:
| Name | ISO98.9-3 Steel Gas Cylinder 1.8L-50L High Pressure Gas Cylinder
High Corrosion Resistance |
| Type | ISO98.9-3 Steel Gas Cylinder 1.8L-50L |
| Water Capacity | 1.8L-50L |
| Outside Diameter(mm) | 102-219 |
Design wall
thickness(mm) | 3.0-6.1 |
| Material | 37Mn |
| Weight(kg) | 3.3-57.9 |
Working pressure (bar) | 150BAR |
| Height(mm) | 325-1598 |
| Standard | DOT/EN/ISO/GB |
ISO9809, DOT, GB, EN certificated welding empty big gas cylinder
(Please find the form) :
Below specification are all for standard sizes, we can also supply
you customized cylinder as you request.
STEEL CYLINDER, ALUMINUM CYLINDER, SEAMLESS STEEL CYLINDER, GAS
CYLINDER
Type
| Outside Diameter | Water Capacity | Height (Without valve) | Weight (Without valve,cap) | Working pressure | Design Wall Thickness | Material Grades |
| ISO102-1.8-150 |
102 | 1.8 | 325 | 3.5 | 150 | 3.0 | 37Mn |
| ISO102-3-150 | 3 | 498 | 5.2 |
| ISO102-3.4-150 | 3.4 | 555 | 5.7 |
| ISO102-4.4-150 | 4.4 | 700 | 7.2 |
| ISO108-1.4-150 | 108 | 1.4 | 240 | 2.9 | 150 | 3.2 | 37Mn |
| ISO108-1.8-150 | 1.8 | 285 | 3.3 |
| ISO108-2-150 | 2 | 310 | 3.6 |
| ISO108-3-150 | 3 | 437 | 4.9 |
| ISO108-3.6-150 | 3.6 | 515 | 5.7 |
| ISO108-4-150 | 4 | 565 | 6.2 |
| ISO108-5-150 | 5 | 692 | 7.5 |
| ISO-140-3.4-150 | 140 | 3.4 | 329 | 5.8 | 150 | 4.1 | 37Mn |
| ISO-140-4-150 | 4 | 373 | 6.4 |
| ISO-140-5-150 | 5 | 448 | 7.6 |
| ISO-140-6-150 | 6 | 523 | 8.8 |
| ISO-140-6.3-150 | 6.3 | 553 | 9.2 |
| ISO-140-6.7-150 | 6.7 | 575 | 9.5 |
| ISO-140-7-150 | 7 | 603 | 9.9 |
| ISO-140-7.5-150 | 7.5 | 640 | 10.5 |
| ISO-140-8-150 | 8 | 673 | 11.0 |
| ISO-140-9-150 | 9 | 753 | 12.2 |
| ISO-140-10-150 | 10 | 838 | 13.5 |
| ISO-140-11-150 | 11 | 893 | 14.3 |
| ISO-140-13.4-150 | 13.4 | 1078 | 17.1 |
| ISO-140-14-150 | 14 | 1123 | 17.7 |
| ISO-159-7-150 | 159 | 7 | 503 | 10.5 | 150 | 4.7 | 37Mn |
| ISO-159-8-150 | 8 | 562 | 11.6 |
| ISO-159-9-150 | 9 | 618 | 12.7 |
| ISO-159-10-150 | 10 | 673 | 13.7 |
| ISO-159-11-150 | 11 | 730 | 14.7 |
| ISO-159-12-150 | 12 | 798 | 16.0 |
| ISO-159-12.5-150 | 12.5 | 810 | 16.2 |
| ISO-159-13-150 | 13 | 841 | 16.8 |
| ISO-159-13.4-150 | 1304 | 863 | 17.2 |
| ISO-159-13.7-150 | 13.7 | 886 | 17.6 |
| ISO-159-14-150 | 14 | 898 | 17.8 |
| ISO-159-15-150 | 15 | 953 | 18.9 |
| ISO-159-16-150 | 16 | 1008 | 19.9 | | | | |
| ISO-180-8-150 | 180 | 8 | 485 | 13.8 | 150 | 5.3 | 37Mn |
| ISO-180-10-150 | 10 | 575 | 16.1 |
| ISO-180-12-150 | 12 | 665 | 18.3 |
| ISO-180-15-150 | 15 | 795 | 21.6 |
| ISO-180-20-150 | 20 | 1020 | 27.2 |
| ISO-180-21-150 | 21 | 1066 | 28.3 |
| ISO-180-21.6-150 | 21.6 | 1092 | 29.0 |
| ISO-180-22.3-150 | 22.3 | 1105 | 29.4 |
| ISO-219-20-150 | 219 | 20 | 698 | 27.8 | 150 | 6.1 | 37Mn |
| ISO-219-25-150 | 25 | 848 | 32.8 |
| ISO-219-27-150 | 27 | 908 | 34.8 |
| ISO-219-36-150 | 36 | 1178 | 43.9 |
| ISO-219-38-150 | 38 | 1238 | 45.9 |
| ISO-219-40-150 | 40 | 1310 | 47.8 |
| ISO-219-45-150 | 45 | 1448 | 52.9 |
| ISO-219-46.7-150 | 46.7 | 1498 | 54.6 |
| ISO-219-50-150 | 50 | 1598 | 57.9 |
Discription:
● 37 Mn steel gas cylinders are used to store breathable air and
industrial gases for use
in a variety of industrial and commercial applications. For
example, nitrogen cylinders and
helium cylinders for industrial use, etc.
● Working pressure of 37Mn steel gas cylinders is 15 Mpa, the service life will be 15 years.
The water capacity varies from 25L to 50L.OD(diameter): 219mm,
232mm. More
specifications are available.
● Steel gas cylinders made of 34CrMo4, 25 Mpa are available as
well.
● All the steel gas cylinders are manufactured according to ISO9809
standard and are
compatible with standard accessories such as valves.
1. Brushed external surface provides a low -maintenance finsh .
2. Cylinders meet or exceed all regulatory standards worldwide.
3. Cylinders cycle -tested in excess of 100,000 cycle at service
pressure .Excess of 12000
cycles at test pressure.
4. Minimum burst pressure tasted up to 2.5 times service pressure
without failure .
Competitive Advantage:
1. Low MOQ: It can meet your promotional business very well.
2. OEM Accepted: We can produce any your design.
3. Good Service: We treat clients as friend.
4. Good Quality: We have strict quality control system .Good
reputation in the market.
5. Fast & Cheap Delivery: We have big discount from forwarder
(Long-term Contract).
6. We have more than 15 years exported experience for high pressure
container products.
