EN 1964 Standard Seamless Steel Gas Cylinder 20-40L Medical Oxygen Cylinder

Shanghai Qilong High Pressure Container Co., Ltd.
Contact Now
    Buy cheap EN 1964 Standard Seamless Steel Gas Cylinder 20-40L Medical Oxygen Cylinder from wholesalers

    Buy cheap EN 1964 Standard Seamless Steel Gas Cylinder 20-40L Medical Oxygen Cylinder from wholesalers
    • Buy cheap EN 1964 Standard Seamless Steel Gas Cylinder 20-40L Medical Oxygen Cylinder from wholesalers
    • Buy cheap EN 1964 Standard Seamless Steel Gas Cylinder 20-40L Medical Oxygen Cylinder from wholesalers

    EN 1964 Standard Seamless Steel Gas Cylinder 20-40L Medical Oxygen Cylinder

    Ask Lasest Price
    Brand Name : TWA
    Model Number : EN 1964 Standard Steel Cylinder 20-40L
    Certification : DOT,ISO,EN,GB
    Price : Negotiate
    Payment Terms : L/C,T/T,30%TT in advance by hydrogen gas cylinder price
    Supply Ability : 6,0000pcs per month
    Delivery Time : 25-35days
    • Product Details
    • Company Profile

    EN 1964 Standard Seamless Steel Gas Cylinder 20-40L Medical Oxygen Cylinder

    EN 1964 Standard Steel Cylinder Hot Sale Pressure 20-40L Medical Use Oxygen Cylinder


    Specifications:


    Name

    EN 1964 Standard Steel Cylinder Hot Sale Pressure 20-40L Medical Use Oxygen Cylinder

    Water Capacity(L)20-40L
    Ouside Diameter204-229mm
    Design wall thickness(mm)3.8-4.8mm
    PacakgeCarton By Nylon net
    Weight(kg)21.7-45kg
    Height(mm)800-1240mm
    Working Pressure(bar)166.7/200bar


    Welding empty medical steel, aluminum hydrogen gas cylinder price (Please find the form) :


    Below specification are all for standard sizes, we can also supply you customized cylinder as you request.


    STEEL CYLINDER, ALUMINUM CYLINDER, SEAMLESS STEEL CYLINDER, GAS CYLT

    Type

    Outside
    Diameter
    (mm)

    Water
    capacity
    (L)

    Design
    wall
    Thickness
    (mm)

    Material

    Height
    (mm)

    Weight
    (kg)

    Working Pressure
    (bar)

    EN1964 204-20-166.7204203.834CrMo480021.7166.7
    EN1964 204-26.8-166.720426.83.834CrMo4104027.5166.7
    EN1964 204-10.7-20020410.74.634CrMo448516200
    EN1964 204-13.4-20020413.44.634CrMo457519200
    EN1964 204-20-200204204.634CrMo481025200
    EN1964 204-26.8-20020426.84.634CrMo4105031.5200
    EN1964 203-13.4-166.720413.45.130CrMo59021166.7
    EN1964 229-40-166.7204404.834CrMo4124045166.7


    Discription:


    ●37 Mn steel gas cylinders are used to store breathable air and industrial gases for use
    in a variety of industrial and commercial applications. For example, nitrogen cylinders and
    helium cylinders for industrial use, etc.


    ●Working pressure of 37Mn steel gas cylinders is 15 Mpa, the service life will be 15 years.
    The water capacity varies from 25L to 50L.OD(diameter): 219mm, 232mm. More
    specifications are available.


    ●Steel gas cylinders made of 34CrMo4, 25 Mpa are available as well.


    ●All the steel gas cylinders are manufactured according to ISO9809 standard and are
    compatible with standard accessories such as valves.



    1.Brushed external surface provides a low -maintenance finsh .


    2.Cylinders meet or exceed all regulatory standards worldwide.


    3.Cylinders cycle -tested in excess of 100,000 cycle at service pressure .Excess of 12000

    cycles at test pressure.


    4.Minimum burst pressure tasted up to 2.5 times service pressure without failure .



    Competitive Advantage:

    1. Low MOQ: It can meet your promotional business very well.


    2. OEM Accepted: We can produce any your design.


    3. Good Service: We treat clients as friend.


    4. Good Quality: We have strict quality control system .Good reputation in the market.


    5. Fast & Cheap Delivery: We have big discount from forwarder (Long-term Contract).


    6.We have more than 15 years exported experience for high pressure container products.



    Q: Are you trading company or manufacturer ?

    A: We are factory.


    Q: How long is your delivery time?

    A: Generally it is 5-10 days if the goods are in stock. or it is 25-35 days if the goods are not

    in stock, it is according to quantity.


    Q: Do you provide samples ? is it free or extra ?

    A: Yes, we could offer the sample for free charge but do not pay the cost of freight.


    Q: What is your terms of payment ?

    A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,

    balance before shippment.
