EN1964-1 Steel Gas Cylinder 3.4-46.7L High Pressure Gas Cylinder
High Corrosion Resistance
Specifications:
| Name | EN1964-1 Steel Gas Cylinder 3.4-46.7L High Pressure Gas Cylinder
High Corrosion Resistance |
| Type | EN1964-1 Steel Gas Cylinder 3.4-46.7L |
| Water Capacity | 3.4-46.7L |
| Outside Diameter(mm) | 140-232 |
Design wall
thickness(mm) | 4.1-5.8 |
| Material | 37/Mn/34CrMo4(TPED) |
| Weight(kg) | 5.8-51.9 |
Working pressure (bar) | 150/200/210/230BAR |
| Height(mm) | 329-1333 |
| Standard | DOT/EN/ISO/GB |
ISO9809, DOT, GB, EN certificated welding empty big gas cylinder
(Please find the form) :
Below specification are all for standard sizes, we can also supply
you customized cylinder as you request.
STEEL CYLINDER, ALUMINUM CYLINDER, SEAMLESS STEEL CYLINDER, GAS
CYLINDER
Type
| Outside Diameter | Water Capacity | Height (Without valve) | Weight (Without valve,cap) | Working pressure | Design Wall Thickness | Material Grades |
| EN140-3.4-150 | 140 | 3.4 | 329 | 5.8 | 150 | 4.1 | 37Mn (TPED) |
| EN140-3.6-150 | 3.6 | 343 | 6.0 |
| EN140-4-150 | 4 | 373 | 6.4 |
| EN140-5-150 | 5 | 448 | 7.6 |
| EN140-6-150 | 6 | 523 | 8.8 |
| EN140-6.3-150 | 6.3 | 553 | 9.2 |
| EN140-6.5-150 | 6.5 | 565 | 9.4 |
| EN140-6.7-150 | 6.7 | 575 | 9.5 |
| EN140-7-150 | 7 | 603 | 9.9 |
| EN140-7.5-150 | 7.5 | 640 | 10.5 |
| EN140-8-150 | 8 | 673 | 11.0 |
| EN140-9-150 | 9 | 753 | 12.2 |
| EN140-10-150 | 10 | 838 | 13.5 |
| EN140-11-150 | 11 | 893 | 14.3 |
| EN140-13.4-150 | 13.4 | 1078 | 17.1 |
| EN140-14-150 | 14.0 | 1123 | 17.7 |
| EN159-4-150 | 159 | 4 | 328 | 7.3 | 150 | 4.7 | 37Mn (TPED) |
| EN159-4.5-150 | 4.5 | 358 | 7.9 |
| EN159-7-150 | 7 | 503 | 10.5 |
| EN159-8-150 | 8 | 562 | 11.6 |
| EN159-9-150 | 9 | 618 | 12.7 |
| EN159-10-150 | 10 | 673 | 13.7 |
| EN159-11-150 | 11 | 730 | 14.7 |
| EN159-12-150 | 12 | 798 | 16.0 |
| EN159-12.5-150 | 12.5 | 810 | 16.2 |
| EN159-13.4-150 | 13.4 | 863 | 17.2 |
| EN159-13.5-150 | 13.5 | 874 | 17.4 |
| EN159-13.7-150 | 13.7 | 886 | 17.6 |
| EN159-14-150 | 14 | 898 | 17.8 |
| EN159-15-150 | 15 | 953 | 18.9 |
| EN159-16-150 | 16 | 1008 | 19.9 |
| EN232-25-150 | 232 | 25 | 772 | 30.0 | 150 | 5.3 | 37Mn (TPED) |
| EN232-25-150 | 30 | 904 | 34.3 |
| EN232-25-150 | 35 | 1035 | 38.6 |
| EN232-25-150 | 40 | 1167 | 43.0 |
| EN232-25-150 | 47 | 1351 | 49.0 |
| EN232-25-150 | 50 | 1430 | 51.6 |
| EN232-25-150 | 52 | 1483 | 53.4 |
| EN232-25-200 | 232 | 25 | 751(M60) | 31.8 | 200 | 5.2 | 34CrMo4 (TPED) |
| EN232-25-200 | 30 | 892 | 36.4 |
| EN232-25-200 | 40 | 1156 | 45.7 |
| EN232-25-200 | 46.7 | 1333 | 51.9 |
| EN232-25-200 | 47 | 1341 | 52.2 |
| EN232-25-200 | 50 | 1420 | 55.3 |
| EN232-25-210 | 232 | 25 | 751(M60) | 31.8 | 210 | 5.5 | 34CrMo4 (TPED) |
| EN232-25-210 | 30 | 892 | 36.4 |
| EN232-25-210 | 40 | 1156 | 45.7 |
| EN232-25-210 | 46.7 | 1333 | 51.9 |
| EN232-25-210 | 47 | 1341 | 52.2 |
| EN232-25-210 | 50 | 1420 | 55.3 |
| EN232-25-230 | 232 | 25 | 751(M60) | 31.8 | 230 | 5.8 | 34CrMo4 (TPED) |
| EN232-25-230 | 30 | 892 | 36.4 |
| EN232-25-230 | 40 | 1156 | 45.7 |
| EN232-25-230 | 46.7 | 1333 | 51.9 |
Discription:
● 37 Mn steel gas cylinders are used to store breathable air and
industrial gases for use
in a variety of industrial and commercial applications. For
example, nitrogen cylinders and
helium cylinders for industrial use, etc.
● Working pressure of 37Mn steel gas cylinders is 15 Mpa, the
service life will be 15 years.
The water capacity varies from 25L to 50L.OD(diameter): 219mm,
232mm. More
specifications are available.
● Steel gas cylinders made of 34CrMo4, 25 Mpa are available as well.
● All the steel gas cylinders are manufactured according to ISO9809
standard and are
compatible with standard accessories such as valves.
1. Brushed external surface provides a low -maintenance finsh .
2. Cylinders meet or exceed all regulatory standards worldwide.
3. Cylinders cycle -tested in excess of 100,000 cycle at service
pressure .Excess of 12000
cycles at test pressure.
4. Minimum burst pressure tasted up to 2.5 times service pressure
without failure .
Competitive Advantage:
1. Low MOQ: It can meet your promotional business very well.
2. OEM Accepted: We can produce any your design.
3. Good Service: We treat clients as friend.
4. Good Quality: We have strict quality control system .Good
reputation in the market.
5. Fast & Cheap Delivery: We have big discount from forwarder
(Long-term Contract).
6. We have more than 15 years exported experience for high pressure
container products.
