High Pressure 10.7L Industrial Steel Gas Cylinder ISO9809 Standard

Ask Lasest Price
Brand Name :	TWA
Model Number :	ISO9809 204-10.7-200
Certification :	DOT,ISO,EN,GB
Price :	Negotiate
Payment Terms :	L/C,T/T,30%TT in advance by big gas cylinder
Supply Ability :	60000 Piece/Pieces per Month big gas cylinder
Delivery Time :	25~35days

Add to Cart

Product Details
Company Profile

High Pressure 10.7L Industrial Steel Gas Cylinder ISO9809 Standard

10.7L ISO9809 Standard Industrial Steel Gas Cylinder

Specifications:

Name	ISO9809 Standard Steel Industrial Gas Cylinder With16kg 200bar10.7L
Type	ISO9809 204-10.7-200 10.7L
Water Capacity	10.7L
Outside Diameter	204mm
Design wall thickness(mm)	4.6mm
Material	34CrMo4
Weight(kg)	16kg
Working pressure	200bar
Height	485
Standard	DOT/EN/ISO/GB

ISO9809, DOT, GB, EN certificated welding empty big gas cylinder (Please find the form) :

Below specification are all for standard sizes, we can also supply you customized cylinder as you request.

Type	Outside diameter (mm)	Water Capacity (L)	Design wall thickness (mm)	Material	Height (mm)	Weight (kg)	Working pressure (bar)
ISO9809 204-107-166.7	204	10.7	3.8	34CrMo4	480	14.2	166.7
ISO9809 204-13.4-166.7	204	13.4	3.8	34CrMo4	570	16.3	166.7
ISO9809 204-20-166.7	204	20	3.8	34CrMo4	800	21.7	166.7
ISO9809 204-26.8-166.7	204	26.8	3.8	34CrMo4	1040	27.5	166.7
ISO9809 204-10.7-200	204	10.7	4.6	34CrMo4	485	16	200
ISO9809 204-13.4-200	204	13.4	4.6	34CrMo4	580	19	200
ISO9809 204-20-200	204	20	4.6	34CrMo4	810	25	200
ISO9809 204-26.8-200	204	26.8	4.6	34CrMo4	1050	31.5	200
ISO9809 204-13.4-166.7	204	13.4	5.1	34CrMo	590	21	166.7
ISO9809 219-38-150	219	38	5.7	34Mn2V	1300	53	150
ISO9809 219-40-150	219	40	5.7	34Mn2V	1360	55	150
ISO9809 219-45-150	219	45	5.7	34Mn2V	1520	62	150
ISO9809 229-40-166.7	229	40	4.8	34CrMo4	1240	45	166.7
ISO9809 229-46.7-166.7	229	46.7	4.8	34CrMo4	1430	51	166.7
ISO9809 229-50-166.7	229	50	4.8	34CrMo4	1520	53	166.7
ISO9809 229-40-200	229	40	5.2	34CrMo4	1250	47	200
ISO9809 229-45-200	229	45	5.2	34CrMo4	1370	52	200
ISO9809 229-50-200	229	50	5.2	34CrMo4	1530	57	200
ISO9809 229-40-200	229	40	5.4	34CrMo34CrMo4	1250	53	200
ISO9809 229-45-200	229	45	5.4	34CrMo34CrMo4	1370	58	200
ISO9809 229-50-200	229	50	5.4	34CrMo34CrMo4	1530	63	200
ISO9809 229-40-150	229	40	5.7	34CrMo	1260	55	150
ISO9809 229-30-200	229	30	5.7	34CrMo34CrMo4	975	44	200
ISO9809 229-40-200	229	40	5.7	34CrMo34CrMo4	1260	55	200
ISO9809 229-45-200	229	45	5.7	34CrMo34CrMo4	1370	58	200
ISO9809 229-50-200	229	50	5.7	34CrMo34CrMo4	1530	65	200
ISO9809 229-50-200	229	50	7.8	34CrMo	1600	83	200
ISO9809 232-40-166.7	232	40	5.5	34Mn2V	1230	52	166.7
ISO9809 232-46.7-166.7	232	46.7	5.5	34Mn2V	1400	58	166.7
ISO980920 232-50-166.7	232	50	5.5	34Mn2V	1500	62	166.7

Discription:

● 37 Mn steel gas cylinders are used to store breathable air and industrial gases for use
in a variety of industrial and commercial applications. For example, nitrogen cylinders and
helium cylinders for industrial use, etc.

● Working pressure of 37Mn steel gas cylinders is 15 Mpa, the service life will be 15 years.
The water capacity varies from 25L to 50L.OD(diameter): 219mm, 232mm. More
specifications are available.

● Steel gas cylinders made of 34CrMo4, 25 Mpa are available as well.
● All the steel gas cylinders are manufactured according to ISO9809 standard and are
compatible with standard accessories such as valves.

1. Brushed external surface provides a low -maintenance finsh .

2. Cylinders meet or exceed all regulatory standards worldwide.

3. Cylinders cycle -tested in excess of 100,000 cycle at service pressure .Excess of 12000

cycles at test pressure.

4. Minimum burst pressure tasted up to 2.5 times service pressure without failure .

Competitive Advantage:

1. The product can meet your promotional business very well.

2. Competitive prices on the basis of high quality.

3. Widely range of gas cylinder products as well as the accessories.

4. Rapid business feedback system.

5. Fast & Cheap Delivery: We have big discount from forwarder (Long-term Contract).

6. We have more than 15 years exported experience for high pressure container products.
